GOLD BUG DP CC (with 5'' DD and 11'' DD Coils) VLF

Fisher Gold Bug II Gold Nugget / Electronic Metal Detector

The Most Sensitive Gold Prospecting Detector Ever Made

• Extreme sensitivity to small gold nuggets

• High-sensitivity dual-controlled ground balance

• Iron discrimination mode rejecting iron and hot rocks

• Deep target audio boost

• Lightweight and hip-mountable

• Available with 6½” or 10” elliptical search coil

• Operating frequency: 71 kHz

• Gold prospecting guide

• Field test report

Recommended for gold nugget hunting

GOLD NUGGET PROSPECTING METAL DETECTOR

Brings a new dimension to metal detecting with ultra-high frequency.

Like the original Gold Bug, the Gold Bug 2 is designed for finding gold nuggets. It offers extreme sensitivity, ultra-high frequency (the highest operating frequency on the market), iron discrimination, dust and moisture shielding, audio boost, and a three-position mineralization switch for efficient operation even in highly mineralized soils. Supported by Fisher’s Limited Lifetime Warranty* for lifetime service and customer satisfaction.

CONTROLS

• THRESHOLD: Small shaft at the back of the control box. Adjusts the threshold tone.

• MODE: Three-position switch:

1. IRON DISC. Mode for rejecting iron and trash.

2. Normal Mode for standard all-metal operation.

3. Audio Boost Mode for hearing faint, deep targets.

• BATTERY TEST/SENSITIVITY: Dual-function potentiometer with switch for audio battery test – Adjusts sensitivity for targets, electrical interference, and ground minerals.

• GROUND REJECT: Dual-knob electronic control to adjust for ground mineral rejection. Small single-turn coarse adjustment knob and large 16-turn fine adjustment knob.

• VOLUME: Turns the device on and adjusts signal response volume.

• HEADPHONES: 1/4" jack for most mono and stereo headphones.

FEATURES

• Powerful 71kHz operation for extreme sensitivity to small gold nuggets

• "IRON DISC." mode for rejecting iron (trash) targets and hot rocks

• Resistant to dust and moisture

• Boosts the audio signal of small and deep targets

• Can be hip or chest-mounted

• Weighs only 2.9 lbs.

• Quartz-crystal locked electronics

• Operates with a single 9-V battery

• Dual-knob ground control for coarse and fine adjustments
